大家好，OPEN AI-CAMERA 正式立项了 Project Kickoff
OPEN AI-CAMERA 是一台基于 Rockchip RV1126B 的开源二轴云台 AI 摄像机，面向端侧 AI 视觉、实时目标跟踪、场景采集与嵌入式视觉研究。
但我们想先说清楚这个帖子是什么：它是项目的主线连载帖。
从今天起到正式发布，3D 结构文件、基础固件、云台控制 Demo、NPU 检测跟踪示例、完整 SDK——每个阶段的产出都会在这里和后续分帖同步。
OPEN AI CAMERA is an open-source 2-axis pan-tilt AI camera built on Rockchip RV1126B. It is designed for edge AI vision, real-time object tracking, scene capture and embedded vision research.
This thread is the project main log. From today until release, we will publish each milestone here: 3D mechanical CAD files, base firmware and PTZ control demos, NPU detection & tracking samples, the full SDK.
为什么做它 Why this project
- 做端侧 AI 视觉的开发者，不该在"黑盒整机"和"从零画板"之间二选一；
- 一台 AI 摄像机应该看得清（8MP）、看得稳（二轴云台）、想得快（3 TOPS NPU 端侧推理），并且这三件事出厂就配齐。
You shouldn’t have to choose between a locked black box and designing a board from scratch. A proper AI camera should see clearly (8MP), stay steady (2-axis pan-tilt), and think on-device (3 TOPS NPU) — with all three ready out of the box.
- Open Source —— 开放SDK源代码和硬件资料。Open source SDK and hardware design files
- AI Powered —— 3 TOPS INT8 NPU，端侧推理不依赖云端。3 TOPS INT8 NPU, on-device inference, no cloud dependency
- Multi-Scenario —— 摄像头、显示、CAN/GPIO/Debug 全引出，机器人、安防、教育、创客都能接。Camera, Display, CAN / GPIO / Debug exposed for robotics, security, education and maker builds
- Community —— 立项即共建，社区意见直接进迭代。Built in the open, shaped by this thread
核心配置 Hardware Specs
| Item | Parameters |
|---|---|
| SoC | Rockchip RV1126B A53 @1.2GHz, 3 TOPS INT8 NPU, H.264/H.265 |
| Memory | 2GB / 4GB LPDDR4 (optional) |
| Storage | 16GB eMMC + MicroSD slot |
| Camera | 8MP, 3840×2160, FOV 123°±5°, 0.6m ~ ∞ focus |
| Display | MIPI-DSI ×1 |
| Audio | 2 Mics + 8Ω 1W Speaker |
| Network | 1G RJ45, 2.4G/5G WiFi + BT5.4, 4G LTE |
| USB | USB3.0 Type-C (data & power) |
| External IO | CAN, GPIO, Debug port |
| Pan-Tilt | 2-axis, integrated |
| Power | USB-C / 12V Jack |
四块核心板卡 Four Boards
| Board | Function |
|---|---|
| 8MP Camera Module | 8MP camera with MIPI CSI input |
| RV1126B Main Board | Quad-core A53 + 3 TOPS NPU, the system brain |
| Interface Board | WiFi + BT 5.4, exposes CAN / SPI / GPIO / UART / MIPI DSI interfaces |
| LTE Board | 4G LTE cellular connectivity |
项目路线图 Roadmap
[x] 立项 & GitHub 仓库搭建。Project Initialization & GitHub repo setup
[x] 项目海报发布，社区公告。Project poster for community announcement
[ ] 发布 3D 机械结构 CAD 文件（STEP / STL）。Release 3D mechanical structure CAD files (STEP / STL)
[ ] 发布基础固件与云台电机控制 Demo。Release base firmware, motor PTZ control demo
[ ] 发布 NPU 目标检测与跟踪示例代码。Release NPU object detection & tracking sample code
[ ] 发布完整 SDK 与工具链。Release full SDK and toolchain
[ ] 社区贡献示例与工具。Community contributed examples & tools
我们会按实际研发进度滚动更新，每个 [ ] 变成 [x] 的时候，就是一篇新分帖。Every [ ] that turns into [x] becomes the next thread update.
链接 Links
- GitHub：T-Firefly-Dev/open-ai-camera · GitHub ← 欢迎 Star / Watch，第一时间收到提交通知。Star / Watch for commit notifications
- Firefly Community：Firefly Community
本帖长期更新，分享比点赞有用。This thread will be updated regularly. Sharing helps more than liking.
Join the Project —— Let’s build this together.
